T3 Partly insulated

General


Are you looking to store slightly temperature-sensitive goods, or do you require a showroom? Then the T3 is the right choice for you. The T3 not only provides protection from weather conditions, but it also prevents condensation from forming on the inside. This is why our customers often choose our T3 when they want to expand their retail space or are looking to protect their vehicles and machines.

The T3 is usually implemented as a semi-permanent structure. Most customers generally choose a bespoke tent because they tend to rent this type of tent for an extended period. In terms of size, but also with available options such as windows, roller shutters, wicket doors and/or sectional overhead doors.

  • Suitable for applications such as temporary storage of vehicles and machines.
  • Width: 3, 5, 6, 8, 10, 12.5, 15, 20, 30 and 40 metres.
  • Length: can be extended indefinitely in 5-metre segments
  • Side height: 1 to 6 metres (variable)
  • Delivery includes a tent book with specifications, fire certification, technical drawings and structural calculations
  • Download T3 Specifications sheet (Partly insulated)
Deels geïsoleerd

Specifications


All our tents are made from PVC tarpaulin: UV-resistant and fire-retardant according to the following European standards: DIN 4102-B1M2BS 5438/7837USA NFPA701. Our European anodised quality aluminium is classified as 6082T6. We use sandwich panels with a thickness of 40 mm, standard B2–S2–D0 fire classification, insulation value Rc = 1.80 m2.k/W. The steelwork is fabricated according to the NEN-1090 standard.

Roof cladding

  • Opaque PVC tarpaulin 750 g/m2
    UV-resistant and fire-retardant according to European standards

Side cladding

  • Sandwich panels measuring 40 mm thick, standard B2-S2-D0 fire classification, insulation value Rc = 1.80 m2.k/W.

Aluminium

  • 6082T6 classification
    European anodised aluminium

Includes

  • Base supports and drive pins

Options

  • Lighting
  • Collision protection measures
  • Ballast blocks as an alternative anchoring method
  • Climate control
  • Flooring systems
  • Sliding doors and/or roller shutters

Maximum wind load

Safety and quality


We believe it’s essential that our staff take pleasure in doing their work, and safety plays a large role. Ensuring a safe work environment is therefore always one of our fundamental principles: in our business policy, our work environment and in our operations.

Tent books following Dutch NEN 8020-41 safety and fire safety standards
Our tents meet all European fire safety and safety standards and are approved according to DIN 4102B1 standards. The tents also come with a tent book from Tentech (per Dutch NEN 8020-41 safety and fire safety standards) containing all the tent specifications, including all structural calculations and technical information.

SCC-certified
Our assembly team is SCC-certified and takes every required safety precaution with high-quality safety materials. Moreover, we invest in training and courses so that we can guarantee both our and your safety.

  • Tent books following Dutch NEN 8020-41 safety and fire safety standards
  • Technical drawing
  • Fire certificate
  • Structural calculations
